NQuire1000 Interactive Kiosk

Product specifications

Operating System
Android 13
Screen Size
10.1”
Interface
USB, Ethernet, Ethernet Expansion
Network Connection
WLAN, WPAN , WWAN
Dimension
251.7(L) × 173.5(W) × 32(H) mm
Decode Capability
2D Barcode, 1D Barcode

Features

2D Barcode
1D Barcode
Android
USB
Ethernet
WiFi
10.1''

Vertical

Retail
Warehouse
Healthcare
Public Sector

Features
Specifications
Downloads
Accessories

Features

Easily Build Applications

The NQuire is built on Android 7.1, allowing for easy development of custom applications.

Easy to Install and Use Anywhere

Ideally suited for shelf mounting or on-counter usage in department stores, supermarkets, small grocery stores, drugs-cosmetic stores, tobacco kiosks, and more.

Highly Customizable with a Broad Range of Features

External SCR, Thermal Printer, Wi-Fi, Bluetooth embedded, Coms included POE.

Snappy Reading Performance

Armed with Newland’s omnidirectional megapixel EM2037 engine (Resolution: 1280*800).

Specifications

Performance	Processor	2.0GHz, octa-core 64-bit processor
	Operating System	Android 13（can be upgrade to higher version）
	Memory	4GB RAM/64GB ROM
	Symbologies	2D Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode. 1D Code128, Code 49, Code 16K, (GS1128) UCC/EAN-128, AIM-128, EAN-8, EAN-13, UPC-E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, CodaBar, Code93, Code 11, Plessey, MSI Plessey, RSS
	Depth of Field(Depend on Barcode and Environment)	EAN-13 70mm-610mm(13mil) Code39 110mm-290mm(5mil) PDF417 110mm-230mm(6.7mil) Data Matrix 110mm-260mm(10mil) QR Code 55mm-410mm(15mil)

Physical/Electrical	Dimensions	251.7(L) × 173.5(W) × 32(H) mm
	Display	10.1” (1280×800), capacitive touch screen
	Keypad	Up/down keys, Vol+/Vol-keys, Menu key
	Notification	speaker and multi-color LEDs
	Sensor	Gravity Sensor, infrared sensor
	GPS	GPS (AGPS), GLONASS, Beidou, Galileo
	Camera	Front camera: 8 megapixels
	Audio	1x Microphone, 2x Speakers 8Ω/1.5W
	Card Slot	Nano+Nano/Nano+TF
	Interface	USB 1x USB Type-C, 1x USB Type-A Ethernet RJ45, support Power-over-Ethernet Expansion 2x GPIO/1x expansion USB/2x series port
	AC Adapte	AC Adapter 12V@3A POE IEEE 802.3 af/at

Environmental	Operating Temperature	-10℃ to 50℃ (14°F to 122°F)
	Storage Temperature	-20℃ to 60℃ (-4°F to 140°F)
	Humidity	5% to 90% (non-condensing)
	Sealing	± 12 kV (Air discharge), ± 6 kV (Direct discharge)
	Sealing	IP54 (front panel)

Barcode Scanning	1D Barcode CMOS (≥ 5 mil)
Barcode Scanning	2D Barcode CMOS (≥ 5 mil)

NFC

13.56MHz

ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693
Support ID Card reading, support reader/writer mode

Wireless	WLAN RADIO	Built-in 802.11 a/b/g/n/ac, support 2.4G and 5G dual frequency
	WWAN RADIO	2G 850/900/1800/1900MHz 3G WCDMA (B1, B2, B5, B8); CDMA: 1X EVDO (BC0); TD-SCDMA: B34/39 4G TDD-LTE (B34, B38, B39, B40, B41), FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b)
	WPAN RADIO	Bluetooth 5.2

I/O Ports	USB Port
	SD Card Slot
	GPIO Port
	Expansion Slot
	DC-in

LAN

Peripherals	Camera
	Audio
	Sensor
	Other H/W
	Functional Keys

Power Supply	Clock Battery
	DC Input
	Power Consumption
	LED Indicator

Multimedia	Video
	Audio

Accessory (Optional)

NFC antenna, MSR card reader

Certificates

Performance

Processor
2.0GHz, octa-core 64-bit processor

Operating System
Android 13（can be upgrade to higher version）

Memory
4GB RAM/64GB ROM

Symbologies
2D Aztec, Composite, CS Code, Maxicode, Micro PDF, Micro QR, PDF 417, QR Code, Data Matrix, DotCode. 1D Code128, Code 49, Code 16K, (GS1128) UCC/EAN-128, AIM-128, EAN-8, EAN-13, UPC-E, UPC-A, ITF, ITF 6, ITF 14, Matrix 2 of 5, Industrial 25, Standard 2 of 5, Code39, ISSN, ISBN, CodaBar, Code93, Code 11, Plessey, MSI Plessey, RSS

Depth of Field(Depend on Barcode and Environment)
EAN-13 70mm-610mm(13mil) Code39 110mm-290mm(5mil) PDF417 110mm-230mm(6.7mil) Data Matrix 110mm-260mm(10mil) QR Code 55mm-410mm(15mil)

Physical/Electrical

Dimensions
251.7(L) × 173.5(W) × 32(H) mm

Display
10.1” (1280×800), capacitive touch screen

Keypad
Up/down keys, Vol+/Vol-keys, Menu key

Notification
speaker and multi-color LEDs

Sensor
Gravity Sensor, infrared sensor

GPS
GPS (AGPS), GLONASS, Beidou, Galileo

Camera
Front camera: 8 megapixels

Audio
1x Microphone, 2x Speakers 8Ω/1.5W

Card Slot
Nano+Nano/Nano+TF

Interface
USB 1x USB Type-C, 1x USB Type-A Ethernet RJ45, support Power-over-Ethernet Expansion 2x GPIO/1x expansion USB/2x series port

AC Adapte
AC Adapter 12V@3A POE IEEE 802.3 af/at

Environmental

Operating Temperature
-10℃ to 50℃ (14°F to 122°F)

Storage Temperature
-20℃ to 60℃ (-4°F to 140°F)

Humidity
5% to 90% (non-condensing)

Sealing
± 12 kV (Air discharge), ± 6 kV (Direct discharge)

Sealing
IP54 (front panel)

Barcode Scanning

1D Barcode CMOS (≥ 5 mil)

2D Barcode CMOS (≥ 5 mil)

NFC

13.56MHz
ISO14443A/B, MIFARE, FeliCa, NFC Forum Tags, ISO15693 Support ID Card reading, support reader/writer mode

Wireless

WLAN RADIO
Built-in 802.11 a/b/g/n/ac, support 2.4G and 5G dual frequency

WWAN RADIO
2G 850/900/1800/1900MHz 3G WCDMA (B1, B2, B5, B8); CDMA: 1X EVDO (BC0); TD-SCDMA: B34/39 4G TDD-LTE (B34, B38, B39, B40, B41), FDD-LTE (B1, B2, B3, B5, B7, B8, B20, B28 a&b)

WPAN RADIO
Bluetooth 5.2

I/O Ports

USB Port

SD Card Slot

GPIO Port

Expansion Slot

DC-in

LAN

LAN

Peripherals

Camera

Audio

Sensor

Other H/W

Functional Keys

Power Supply

Clock Battery

DC Input

Power Consumption

LED Indicator

Multimedia

Video

Audio


Accessory (Optional)

Accessory (Optional)
NFC antenna, MSR card reader

Certificates

Certificates
